| ACP-2010MB-00CE |
| Disk Drive Bay |
Slim ODD |
- |
| 5.25 External Bay |
1 |
| 3.5 External Bay |
1 |
| 3.5 Internal Bay |
2 |
| Cooling |
Fan |
2 (8 cm /47 CFM each) + 1 (6 cm /28 CFM) for SAS/SATA storage unit |
| Air Filter |
Yes |
| System Fan |
System fan speed referring to chassis thermal sensor, or CPU temperature |
| Front I/O Interface |
USB2.0 |
2 |
| PS/2 |
1 |
| Miscellaneous |
LED Indicators |
Power, HDD, Temperature, FAN Status |
| Rear Panel |
Two 9-pin D-Sub openings |
| Intelligent System Module |
Remote Monitoring |
CPU/System fan speed , CPU/System temperature , motherboard voltage |
| Environment |
Operational Temperature |
0 ~ 40° C (32 ~ 104° F) |
| Non-Operational Temperature |
-20 ~ 60° C (-4 ~ 140° F) |
| Operating Humidity |
10 ~ 85% @ 40° C, non-condensing |
| Non-Operating Humidity |
10 ~ 95% @ 40° C, non-condensing |
| Operating Vibration (5 ~ 500 Hz) |
1 Grms |
| Non-Operating Vibration |
2 Grms |
| Operating Shock |
10 G (with 11 ms duration, half sine wave) |
| Non-Operating Shock |
30 G |
| Physical Characteristics |
Dimensions (W x H x D) |
480 x 44 x 497 mm (19" x 1.7" x 19.6") |
| Weight |
10.7 kg (23.5 lb) |
