| HPC-7442MB-00XE |
| Disk Drive Bay |
Slim ODD |
1 |
| 3.5 Internal Bay |
1 |
| Hots-swap External |
4 (compatible with 3.5" or 2.5" devices) |
| Cooling |
System Fan |
1 (12 cm /114 CFM) + 1 (8 cm/55 CFM) |
| Air Filter |
Yes |
| Front I/O Interface |
USB2.0 |
2 |
| Miscellaneous |
LED Indicators |
Power, HDD, temperature, fan, LAN1, and LAN2 |
| Rear Panel |
Five 9-pin D-Sub & one 68-pin SCSI openings |
| Intelligent System Module |
Remote Monitoring |
CPU/System fan speed , CPU/System temperature , motherboard voltage |
| Environment |
Operational Temperature |
0 ~ 50° C (32 ~ 122° F) |
| Non-Operational Temperature |
-40 ~ 70° C (-40 ~ 156° F) |
| Operating Humidity |
10 ~ 95% @ 40° C, non-condensing |
| Non-Operating Humidity |
10 ~ 95% @ 60° C, non-condensing |
| Operating Vibration (5 ~ 500 Hz) |
1 Grms |
| Non-Operating Vibration (5 ~ 500 Hz) |
2 G |
| Shock |
10 G (with 11 ms duration, half sine wave) |
| Physical Characteristics |
Dimensions (W x H x D) |
482 x 177 x 600 mm (19" x 7.0" x 23.6") |
| Weight |
18.5 kg (40.68 lb) |
