ACP-4020MB-00XE |
| Disk Drive Bay |
Slim ODD |
1 |
1 |
| Drive Bay |
3.5 External Bay |
2 |
2 |
| 3.5 Internal Bay |
- |
- |
| Disk Drive Bay |
2.5" Internal |
1 |
1 |
| Cooling |
System Fan |
2 (9 cm / 53 CFM) |
2 (9 cm / 53 CFM) |
| Air Filter |
Yes |
Yes |
| Front I/O Interface |
USB3.0 |
2 |
2 |
| Miscellaneous |
LED Indicators |
Power, HDD, temperature, fan, LAN1, and LAN2 |
Power, HDD, temperature, fan, LAN1, and LAN2 |
| Rear Panel |
One 9-pin D-Sub opening |
Five 9-pin D-Sub & one 68-pin SCSI openings |
| Intelligent System Module |
Remote Monitoring |
CPU/System fan speed , CPU/System temperature , motherboard voltage |
CPU/System fan speed , CPU/System temperature , motherboard voltage |
|
|
Operational Temperature |
0 ~ 40° C (32 ~ 104° F) |
0 ~ 40° C (32 ~ 104° F) |
| Non-Operational Temperature |
-40 ~ 70° C (-40 ~ 156° F) |
-40 ~ 70° C (-40 ~ 156° F) |
| Operating Humidity |
10 ~ 85% @ 40° C, non-condensing |
10 ~ 85% @ 40° C, non-condensing |
| Non-Operating Humidity |
10 ~ 95% @ 60° C, non-condensing |
10 ~ 95% @ 60° C, non-condensing |
| Operating Vibration (5 ~ 500 Hz) |
1 Grms |
1 Grms |
| Non-Operating Vibration (5 ~ 500 Hz) |
2 G |
2 G |
| Operating Shock |
10 G (with 11 ms duration, half sine wave) |
10 G (with 11 ms duration, half sine wave) |
|
|
30 G |
30 G |
| Physical Characteristics |
Dimensions (W x H x D) |
482 x 177 x 348 mm (19'' x 7.0'' x 13.7'') |
482 x 177 x 348 mm (19'' x 7.0'' x 13.7'') |
| Weight |
8.5 kg (18.7 lb) |
8.5 kg (18.7 lb) |
